A randomized 25 question test from a pool of 469 questions, good luck!
There are multiple parts to a large industrial water tube boiler. Which of the answers below is best described as the area where boiler water is equalized, and scale is deposited?
The graph below is an example of a typical positive displacement compressor. Which of the numbered points would best be described as the end of the discharge stroke?
Gasoline is a complex hydrocarbon blend. Which of the blending ratios would use quantity controllers and pulse flowmeters on each stream to create the blend ratio?
On a typical boiler control system, there are four main points of control. Which of the answers below would best be manipulated to control the steam drum level?
Which of the responses below is best described as although slower than ΒΌ amplitude decay, the response is stable and has no overshoot?
There are numerous undertakings in developing an SIS, this is called the safety life cycle. Which of the terms below relates best to the SIL required to satisfy an RRF of 87
Because steam demands can vary, there are several control methods that work in concert to ensure efficient boiler operation. Which of those strategies would be to control the the proper air-to-fuel ratios for varying boiler demands?
One of the more common applications for ratio control is fuel to air control schemes. Which of the control schemes below would use a a signal arriving at both the air and fuel controllers from the firing demand controller?
Boiler feedwater treatment is a vital component for the smooth operation of an industrial boiler. Which of the conditioning methods below is comprised of filtration and softening before entering the boiler feedwater system
Because steam demands can vary, there are several control methods that work in concert to ensure efficient boiler operation. Which of those strategies would be to control the pressure of the furnace?
Because steam demands can vary, there are several control methods that work in concert to ensure efficient boiler operation. Which of those strategies would be to control the rate of combustion?
Because steam demands can vary, there are several control methods that work in concert to ensure efficient boiler operation. Which of those strategies would be to control the the proper air-to-fuel ratios for varying boiler demands?
A Split range control system divides the total span of the controllers output. If FCE "A" was set to 0%-50% of the CO, and FCE "B" was set from 50%-100%of CO output, what would be the total percent of stroke used for each valve at 34% CO output signal?
In an industrial application, there are systems where two or more boilers supply a main header. Which of the terms below would best describe the main steam header pressure controller?
Electric switches and transmitters make up the bulk of the sensors in a safety system. Which type of sensor architecture below is best described as a shutdown that can be initiated by either of it's two components?
In the protocol specifications of Modbus, there are only four types of registers that can be accessed by the master. Which of the answers below expresses the register size and permissions of a coil?
There are several ways to control the pressure in a distillation column. Which of the answers below is would be the best type of pressure control for a typical distillation column?
Boiler feedwater treatment is a vital component for the smooth operation of an industrial boiler. Which of the conditioning methods below is comprised of Mechanically removing gases from the feedwater?
Direct and indirect ratio control have an inherent problem that requires the addition of feedback trim. Which of the answers below best describes that issue?
In the arena of process control, there are some that deal with more than one FCE at a time. Which of the control strategies below would be best suited for processes that need 2 different manipulated variables to be used at the same time?
Using the picture below, which variable is best defined as "manipulated"?
In the reciprocating compressor system, there are numerous specialized components. Which of the components below would be best described as one that increases efficiency by preventing over heating between stages?
In industry, distillation columns have grown to encompass the needs that are required. Which of the columns below would best be described as one that removes distillate form multiple points on the column?
Which of the terms below can be best described as supplies the individual devices with data and power from the trunk line in an H1 transmission system?
There are numerous undertakings in developing an SIS, this is called the safety life cycle. Which of the terms below relates best to the SIL required to satisfy an RRF of 8734?
