Instrumentation: FIRST PERIOD

A randomized 100 question test from a pool of 1236 questions, good luck!

Air and iron are the two types of electromagnetic cores. Choose from the answers below to explain why an iron core is more preferable than an air one.
An instrument technician sometimes has to do calibrations while the process is still running. Which of the terms below identifies a calibration done on a live process?
There are several different ways to apply force to an actuator. Which one of the methods below would a rack and pinion actuator use for operation?
Scaffolds use is daily occurrence at most job sites. Any scaffold that is constructed must be designed to handle _____ times the potential load placed on it. Use that answers below to correctly fill in the blank.
There are several different notations on a length of pipe. Which of the notations below would have the thinnest pipe wall?
How many coulombs of charge pass though a given point in 1 second, if the current is 16mA
There are several methods to routing and protecting cable, tubing, and insulated impulse lines. Which of the answers below would be best used to support an in-line instrument?
There are many studies on how pressure and force affect fluids. "Fluid volume does not affect pressure." is one of the principles of which answer below?
When servicing or troubleshooting a valve there are several steps that must be completed. In controlling hazardous energy, removing securing devices and any isolation points once work area is deemed safe, would be which of the steps below?
In the WHMIS system, "Infectious materials" is represented by which hazard class? Choose from the following answers.
In the figure below, R1= 10 ohms, R2=6 ohms, and R3=4 ohms, with the battery producing 40 V, what is the power absorbed by R3?
(310101c) Although soldered fittings for tube can be used on pressure and DWV applications, there are some differences between the fittings. Which of the answers below describes one of the major differences that the DWV fittings have when compared to pressure fittings??
The sliding Vernier calipers are a widely used measuring device. Which of the parts below best relates to "7"?
Modification of certain safety enclosures by mechanical means is allowed in certain conditions. Which of the answers below would describe the conditions is required for modification to an explosion-proof enclosure?
Material safety data sheets are required to be accompany all controlled substances from the supplier. There are _______ that make up these sheets, providing more detail than the label. Use the answers below to fill in the blank
(310105d) The displacement of an applied force is a measurable quantity. Which of the terms below would be use "J" as it's unit of measurement?
For every gas law there is a corresponding equation. Which of the gas laws below is represented by the equation "V₁T₂=V₂T₁"?
If a closed tank is pressurized to 134.345 kPa and the pressure gauge at the bottom of the tank reads 169.456 kPa, what head (in feet) of a liquid with a R.D. of 0.24 is contained in the tan
Gauge pressure is calculated by?
Many electrical properties are a measured quantity, needing a unit of measurement. Which of the units below would be the correct unit of measurement for inductance?
In the SI system, the unit for time is?
In a simple circuit, if E=4 V and R=2 ohms, what is the current of the circuit?
Bourdon measuring elements have tubes that are classified into three broad categories. Which of the tube types below would be the most sensitive to pressure changes?
With the proper formula "Work" is a measurable quantity. Which answer below represents the "displacement" part of that equation?
Hazardous locations in industry have been grouped for ease of understanding Which of the classes below is best described an area with easily ignitable fibers or flyings, but the concentration of these fibers or flyings are not in quantities that would produce ignitable mixtures?
By the early 1800's, there had been several gas laws discovered. Which of those laws below is best described as "the relationship between the volume and temperature in a fixed mass of gas."?
There are many studies on how pressure and force affect fluids. "Fluid pressure is proportional to depth." is one of the principles of which answer below?
A parallel circuit reacts in specific ways to the to an open circuit. Which of the answers below best describes the reaction of the total line resistance to an open circuit?
The relationship between the 4 temperature scales is very important to understand. Which of the answers below correctly corresponds to 373.15 K?
(310101c) There are several different styles of flared and flareless fittings. Which of the styles below would commonly use a two ferrule style fitting?
In this circuit R1= 4 ohms, R2= 5 ohms and R3=9 ohms with the battery producing 40V. What is the voltage drop over R3?
The CEC generates a hazardous area result by investigating the contents of the area. Which of the designations below is based on an explosive atmospheres duration and frequency of occurrence?
There are many different parts to a parallel circuit. Which of the answers below corresponds correctly with the number "2" in the picture below?
In this circuit R1= 4 ohms, R2= 5 ohms and R3=9 ohms with the battery producing 40V. What is the voltage drop at R1?
Lifting a load with rigging is an involved and potentially dangerous task. When working with slings, which of the angles below is the commonly used safe lifting angle?
Proper choices need to be made with the mounting of instruments. Which of the answers below would be a disadvantage of a instrument stand that has a cable mount?
Calculate the relative density for a liquid whose density is =743.2 kg/m³.
Calculate the gain when a change from 1.55 psig to 2.15 psig in nozzle backpressure and a change from 3 psig to 20 psig in the relay output occurs.
Reduce and state answer as a proper or mixed fraction: ¹²⁄₄₈.
Which type of pilot valve has one supply connection and two output connections?
(310102m) The relationship between resistors, capacitors and time intervals is an interdependent one. Which of the answers below would be the reaction of a capacitor if you replaced a it with a smaller one in a simple circuit?
State 3 ⅞ as a mixed fraction.
In the SI system, the unit used for mass is?
There are numerous types and styles of valves in industry. Which of the actuators below best represents the following picture?
If a compound were to be broken down into its simpler components, of the options below, what would it be called?
If a battery has a rating of 133 Ah, theoretically it could provide 5.75 A for how long?
Isolate for"h" in the following equation y=(h-t)/r
(310103d) There are several different designs of regulator. Which of the loading element designs below would have to slowest response to changes in downstream pressures?
There are several common precision measurement tools available in industry. Which of the answers below best represents the tool pictured below?
There are a number of factors determining the resistance to current of a material. Which one of the terms below would be best described as "A greater amount of free electrons reside in a conductor of greater diameter per linear unit."
(650101a) There are three main sections in the occupational health and safety legislation in Alberta. Which of the sections below best relates to the workers rights and responsibilities?
There are 3 major components to a zener intrinsically safe barrier. Which of the answers below would be best describe the component that limits the voltage delivered to the field device?
What is the gain if nozzle backpressure changes from 1.35 psig up to 2.5 psig, and the relay output changes from 4 psig to 17 psig?
There are several types of purge/pressurization permits that are available. Which of the permits below would best be used when an enclosures classification must be reduced from Class I, Zone 1 to non-hazardous?
A mass of 5 kg is placed on top of a spring and that spring compresses 7 cm. What is it's spring rate?
Chart recorders have some specialized applications in industry. Which of those applications would best make use of the multiple temperature inputs available?
(310104a) There are only two major parts to a sliding stem control valve assembly. Which of the components below would best be described as a device that regulates flow with differential pressure??
There are many electrical symbols used in industry today. Which of the answers below correctly identifies the following symbol?
Ladders have specific designs for specific applications. Which of the answers below correctly identifies the ladder in the following picture?
Calculate the gain when a change from 0.25 psig to 1.5 psig in nozzle backpressure and a change from 3 psig to 20 psig in the relay output occurs.
Of the methods to render a container safe for hotwork, which of the following is the most common and most effective?
(310101c) Copper tube is the most used type of tubing in industry. What type of copper tubing would a colour code of red represent?
There are a number of factors determining the resistance to current of a material. Which one of the terms below would be best described as "The amount of opportunities for the atoms of the conductor to affect current flow per linear unit"
Reduce ¹⁵⁄₄₅ and state as a proper or mixed fraction.
The common methods for classifying pipe is by NPS and DN. Which of the answers below are these methods used for the classification of piping?
(310102n) The Canadian Electrical code (CEC) encompasses all standards for electrical/instrumentation work. Which of the sections of that code below would relate best to the grounding circuits that are isolated?
(310103d) There are several essential components to a pressure regulator. Which of the components below would be used as a measuring element?
What is the smallest charged particle?
There are two very common types of metric vernier calipers. Which of the answers below best represents the minimum accuracy of a metric Vernier caliper?
Covert 34.5 kPa to psi.
For every gas law there is a corresponding equation. Which of the gas laws below is represented by the equation "PV=nRT"?
Having to convert between SI and USCS measurements is commonplace in industry today. Which of the answers below is the correct conversion for 45 lbf?
Linear motion negative feedback system consists of:
There are several different notations on a length of pipe. Which of the notations below would have the largest pipe diameter?
"A valve that has a low pressure drop at high flow rates.", is the best description of which of the terms below?
If a closed tank is pressurized to 10 psig and the pressure gauge at the bottom of the tank reads 45 psig, what head (in meters) of a liquid with a R.D. of 0.78 is contained in the tank
(310101c) There are many specialized applications for copper tube. Which of the copper tube colour code would be used in a refrigeration system?
Factors affecting induced voltage include:
(310101c) Although soldered fittings for tube can be used on pressure and DWV applications, there are some differences between the fittings. Which of the answers below describes one of the major differences that the DWV fittings have when compared to pressure fittings??
Each one of the installations of purge/pressurization has its own requirements for additional equipment. Which of the installations below would also require a low purge gas pressure audible alarm only?
There are many electrical terms that have symbols to describe them in equations. Which of the terms below is best referred to as "Ꜫᵣ" in an equation?
(310105d) The displacement of an applied force is a measurable quantity. Which of the terms below would be equal to "W" as a of measurement?
"Is a triangle with two congruent sides and congruent base angles." is a description of which mathematical term?
Two pieces of eye protection should be used together when grinding or chipping. Choose the best answer from the selection below.
(310103d) There are several different designs of regulator. Which of the elements below are you affecting when you adjust spring compression?
In a simple circuit, if I= 2 A and R=3 ohms, what is the voltage drop over the resistor of the circuit?
A pneumatic level transmitter, with an output range of 20-100 kPa, is being used to assess the fluid level in a cylinder though an input range of 0-14 meters. What is the transmitter output signal if the fluid level is at 8.65 meters?
"The law that the algebraic sum of the products of the current and resistance in the conductors forming a closed loop in a network is equal to the algebraic sum of the electromotive forces in the loop." This statement is the best description of which electrical law below?
There are several terms which relate to charging of a capacitor. Which of the terms below would apply to the period while the capacitor gets to 5τ?
State the following number, 15.198*10¹³ using engineering notation and round the answers to 3 significant digits.
There are many studies on how pressure and force affect fluids. "Fluid pressure is exerted in all directions." is one of the principles of which answer below?
Before entering a confined space for the first time or re-entering after a break, it is a good practice to do which of the following?
A mass of 6 kg is placed on top of a spring and that spring compresses 7 cm. What is it's spring rate?
Loss of pressure is a by product of several factors in a piping system. If the length of a straight section of pipe has the diameter doubled, which of the answers below would be the result?
If it were necessary to operate an 50-300 kPa valve actuator, but you had a 20-80 kPa control signal, the relay used would be?
(310104b)There are several connection methods available for valve installation. Which of the connection methods below would be referred to as a "Van Stone" flange connection?
Bourdon measuring elements have tubes that are classified into three broad categories. Which of the tube types below would be used in applications having 145 kPag?
The methods to mount an instrument are as varied as the instruments themselves. Which of the mounting methods below would capillary or impulse line to the instrument be used?
What percentage of 35 is 21?
Oxygen is a vital component of the combustion process. Which of the answers below best describes the effects of combustion if an amount of gas and oxygen are equal in volume?
